Wagner Tuning Ford Fiesta Mk8 ST Competition Intercooler Kit

Wagner Tuning Ford Fiesta Mk8 ST Competition Intercooler Kit

The WAGNER TUNING high performance intercooler has got a new competition core (Tube Fin) which was developed especially for the requirements of the Ford Fiesta ST. This high performance core offers an 150% larger frontal surface and 86 % more core volume compared to the stock intercooler.

The aluminium cast end tanks were designed in CAD and optimised in CFD simulations (for an ideal internal airflow). An incorporated air baffle inside the intercooler inlet ensure a uniform filling of the intercooler. The result is a excellent cooling property with a minimal back pressure. The newly developed competition high-performance core is very light and provides the adjoining components (for example the watercooler) enough air flow. That's why this kit is perfect for racing use. An optimal cooling effect of the charged air with a significant increase in performance!

An anti-corrosion powder coating with perfect heat-conducting properties protects the WAGNER TUNING intercooler from all environmental influences, so a lasting and optimal cooling effect can be guaranteed. The installation is done by replacing the original intercooler and is easy to perform (plug and play). All our products are subject to a continuous quality monitoring.

Inlet diameter: √ò67mm/2.63" (stock click-connection). Outlet diameter √ò61mm/2.4" (stock click-connection)

Stock Intercooler Dimensions:
690 x 140 x 75 mm / 27.2 x 5.5 x 2.9"
V = 7.25 L / 442.4 Inch³
A = 966 cm² / 149.7 Inch²

WAGNER TUNING Intercooler Dimensions:
620 x 390 x 56 mm / 24.4 x 15.3 x 2.2"
V = 13.5L / 823.8 Inch³
A = 2418 cm² / 374.8 Inch²

Kit Includes
Intercooler
Mounting material
Installation instruction

Fitment: Ford Fiesta ST MK8
