• Xtreme Performance - 200mm Rigid Ceramic Twin Plate Clutch Kit Incl Flywheel 1200Nm - Nissan Primera P10 (95-96)
1 1

Xtreme Performance

Xtreme Performance - 200mm Rigid Ceramic Twin Plate Clutch Kit Incl Flywheel 1200Nm - Nissan Primera P10 (95-96)

Xtreme Performance - 200mm Rigid Ceramic Twin Plate Clutch Kit Incl Flywheel 1200Nm - Nissan Primera P10 (95-96)

SKU: KNI20524-2E

£1,285.80 GBP
£1,285.80 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.
Xtreme Motorsport 200mm twin plate
The Xtreme 200mm Race Clutch was developed with a focus on those interested in a cost-effective alternative compared to other race style clutch kits on the market but without having to compromise on quality.

The 200mm Race Clutch Kits consist of a Billet Flywheel, Solid-centered Ceramic Clutch Plates, Cover assembly, Thrust Bearing & Carrier / or the Internal Concentric Slave Cylinder (CSC).

Product Features:

  • Torque capacity 1200Nm
  • Kit contains everything you need for a successful installation + accessories
  • Rigid driven discs (individual hubs)
  • Push type billet alloy cover
  • 4140 Chromoly pressure & intermediate plates
  • Hardened steel wear posts
  • Low inertia
  • Serviceable components
  • SFI certified design
Clamping Force 1000kg
Torque Rating 1200Nm
Bearing Contact Diameter 44-52mm
Bearing Load (@ 48mm) 218kg
Release Travel Required 6mm
Assembly Mass (without flywheel) 7kg
Disc Set Static Mass 1.75kg
Friction Thickness New 7mm (0.275")
Friction Thickness Worn 6.48mm (0.255")

Applications

- Nissan/100NX/B13 | 2.0 GTI/1991.03-1994.10/SR20DE 1998 Petrol 105 kW 143 BHP (1991.03 - 1994.10) , \n - Nissan/Almera Tino/2.0/2000.08-2003.01/SR20DE 1998 Petrol 100 kW 136 BHP (2000.08 - 2003.01) , \n - Nissan/Almera/N15 | 2.0 GTi/1996.07-2000.03/SR20DE 1998 Petrol 105 kW 143 BHP (1996.07 - 2000.03) , \n - Nissan/Primera/P10 | 2.0 GT/1990.06-1996.01/SR20DE 1998 Petrol 110 kW 150 BHP (1990.06 - 1996.01) , \n - Nissan/Primera/P10 | 2.0/1995.01-1996.06/SR20DE 1998 Petrol 92 kW 125 BHP (1995.01 - 1996.06) , \n - Nissan/Primera/P11 | 2.0 16V/1996.06-2002.07/SR20DE 1998 Petrol 110 kW 150 BHP (1996.06 - 2002.07) , \n - Nissan/Primera/P11 | 2.0 16V/1996.06-2001.12/SR20DE 1998 Petrol 105 kW 143 BHP (1996.06 - 2001.12) , \n - Nissan/Primera/P11 | 2.0 16V/1999.08-2002.07/SR20DE 1998 Petrol 103 kW 140 BHP (1999.08 - 2002.07) , \n - Nissan/Primera/P11 | 2.0 16V/1996.06-2002.07/SR20DE 1998 Petrol 96 kW 131 BHP (1996.06 - 2002.07) , \n - Nissan/Primera/P11 | 2.0 16V/1996.06-2002.07/SR20DE 1998 Petrol 85 kW 115 BHP (1996.06 - 2002.07) , \n - Nissan/Primera/P10 | 2.0/1990.06-1993.04/SR20DE 1998 Petrol 105 kW 143 BHP (1990.06 - 1993.04) , \n - Nissan/Primera/W10 | 2.0/1994.07-1998.01/SR20DE 1998 Petrol 110 kW 150 BHP (1994.07 - 1998.01) , \n - Nissan/Primera/WP11 | 1.8 16V/1999.08-2001.12/QG18DE 1769 Petrol 84 kW 114 BHP (1999.08 - 2001.12) , \n - Nissan/Primera/WP11 | 2.0 16V/1999.08-2001.12/SR20DE 1998 Petrol 103 kW 140 BHP (1999.08 - 2001.12) , \n - Nissan/Primera/WP11 | 2.0 16V/1998.04-2001.12/SR20DE 1998 Petrol 96 kW 131 BHP (1998.04 - 2001.12) , \n - Nissan/Primera/WP11 | 2.0 16V/1996.06-2001.12/SR20DE 1998 Petrol 85 kW 115 BHP (1996.06 - 2001.12) , \n - Nissan/Sunny/B13/N14 | 2.0 16V/1990.10-1995.05/SR20DE 1998 Petrol 105 kW 143 BHP (1990.10 - 1995.05) , \n - Nissan/Sunny/B13/N14 | 2.0 GTI 16V/1990.10-1995.05/SR20DE 1998 Petrol 105 kW 143 BHP (1990.10 - 1995.05) ,

Additional Info

Clutch Disc Diameter (mm): 200\nClutch Disc Spline Count: 18\nClutch Disc Spline Diameter (mm): 20.5\nTorque (Nm): 1200\nFlywheel Step: +2.2mm\nDesign: Twin Plate\nStage: Multiplate - track use only\nTech Bulletins: \nClamp Load: 1100Kg\nRecommended for: Motorsport\nRing Gear Tooth count: \nAdditional infotmation:

200mm Twin Plate

Vehicle group: Nissan Primera P10

Additional info: Parameter 1: 1200 | Parameter 2: Motorsport | Parameter 3: Single Mass Flywheel

Fitment details:

Make / Model / Variant / Year Engine Description Note Parameter 1 Parameter 2 Parameter 3
Nissan Primera P10 | 2.0 (1995.01-1996.06) SR20DE 1998 Petrol 92 kW 125 BHP (1995.01 - 1996.06) 1200 Motorsport Single Mass Flywheel
Nissan Primera P10 | 2.0 (1990.06-1993.04) SR20DE 1998 Petrol 105 kW 143 BHP (1990.06 - 1993.04) 1200 Motorsport Single Mass Flywheel
Nissan Primera P10 | 2.0 GT (1990.06-1996.01) SR20DE 1998 Petrol 110 kW 150 BHP (1990.06 - 1996.01) 1200 Motorsport Single Mass Flywheel
Xtreme products are special order and may be on backorder. If you require this urgently please get in touch before ordering to check stock. You will be contacted within 24 hours of your order if it is on backorder
