Xtreme Performance Clutch Kit Heavy Duty Sprung Ceramic 520Nm - BMW 3-Series E30 (88-90)

Recommended for: Motorsport Applications

These kits are available with sprung ceramic friction discs and are designed for motorsport applications where higher heat and torque capacity is required. These can also be used in some road applications.

• Torque capacity 520Nm
• Clamp load Increased over standard
• Sprung Ceramic Friction Disc
• Heavy Duty Pressure Plate
• Kit contains everything you need for a successful installation + accessories

The sprung ceramic range of kits have been developed for motorsport applications where a higher heat and torque capacity is required. These discs utilise a sprung hub that helps to reduce shock loading and are commonly used in track cars that retain the factory transmission.

At Xtreme Clutch, we strive to offer a variety of clutch options for each vehicle to ensure a clutch solution is available for every vehicle application. Whether you are modifying a road vehicle or building a race car from scratch, we have the clutch solution for you. Our upgrades are divided into different stages depending on the friction disc material and the number of friction discs.

Xtreme Performance upgrade kits are available with everything you need for a successful installation + accessories you may want to upgrade or replace while the gearbox is out of the vehicle.

Applications

- BMW/3-Series/E30 | 320is/1988-1990/1990cc | 141KW | 192HP | S14 B20 (204EA) (1988-1990) , \n - BMW/3-Series/E30 | M3/1988-1991/2302cc | 143KW | 195HP | S14 B23 (234EA) (1988-1991) , \n - BMW/3-Series/E30 | M3/1986-1991/2302cc | 143KW | 195HP | S14 B23 (234EA);S14 B23 (234S1);S14 B23 (234S2) (1986-1991) , \n - BMW/3-Series/E30 | M3/1987-1989/2302cc | 147KW | 200HP | S14 B23 (234EA);S14 B23 (234S2) (1987-1989) , \n - BMW/3-Series/E30 | M3/1986-1990/2302cc | 158KW | 215HP | S14 B23 (234EA);S14 B23 (234S2) (1986-1990) , \n - BMW/3-Series/E30 | M3 EVO I 2.3/1988-1990/2302cc | 162KW | 220HP | S14 B23 (234EA) (1988-1990) , \n - BMW/3-Series/E30 | 323i/1982-1983/2316cc | 102KW | 139HP | M20 B23 (236EB) (1982-1983) , \n - BMW/3-Series/E30 | 323i/1983-1986/2316cc | 110KW | 150HP | M20 B23 (236EC);M20 B23 (236EW) (1983-1986) , \n - BMW/3-Series/E30 | M3 EVO II 2.5/1990-1992/2467cc | 175KW | 238HP | S14 B25 (254S1) (1990-1992) ,

Additional Info

Clutch Disc Diameter (mm): 225\nClutch Disc Spline Count: 10\nClutch Disc Spline Diameter (mm): 29\nTorque (Nm): 520\nFlywheel Step: 0\nDesign: Single Plate\nStage: Stage 2\nTech Bulletins: \nClamp Load: \nRecommended for: Track - Stage 2\nRing Gear Tooth count: \nAdditional infotmation:

Single Plate

Vehicle group: BMW 3-Series E30

Additional info: Parameter 1: 520 | Parameter 2: Track Use | Parameter 3: Not included

Fitment details:

Make / Model / Variant / Year	Engine	Description	Note	Parameter 1	Parameter 2	Parameter 3
BMW 3-Series E30 | 320is (1988.05-1990.12)	S14 B20 (204EA) 1990 Petrol 141 kW 192 BHP (1988.05 - 1990.12)			520	Track Use	Not included
BMW 3-Series E30 | M3 (1986.07-1991.06)	S14 B23 (234EA), S14 B23 (234S1), S14 B23 (234S2) 2302 Petrol 143 kW 195 BHP (1986.07 - 1991.06)			520	Track Use	Not included
BMW 3-Series E30 | M3 (1987.02-1989.05)	S14 B23 (234EA), S14 B23 (234S2) 2302 Petrol 147 kW 200 BHP (1987.02 - 1989.05)			520	Track Use	Not included
BMW 3-Series E30 | M3 (1986.01-1990.10)	S14 B23 (234EA), S14 B23 (234S2) 2302 Petrol 158 kW 215 BHP (1986.01 - 1990.10)			520	Track Use	Not included
BMW 3-Series E30 | M3 EVO I 2.3 (1988.10-1990.10)	S14 B23 (234EA) 2302 Petrol 162 kW 220 BHP (1988.10 - 1990.10)			520	Track Use	Not included
BMW 3-Series E30 | M3 EVO II 2.5 (1990.01-1992.01)	S14 B25 (254S1) 2467 Petrol 175 kW 238 BHP (1990.01 - 1992.01)			520	Track Use	Not included

Xtreme products are special order and may be on backorder. If you require this urgently please get in touch before ordering to check stock. You will be contacted within 24 hours of your order if it is on backorder
