	The Xtreme 184mm Race Clutch is an economically priced solution for those wanting a strong Race clutch without having to compromise on quality. The Race Clutch is a lightweight design for when every second counts.
	Ø184mm Light Diaphragm (2.6mm) Ø184mm Heavy Diaphragm (2.8mm) Clamping Force 950kg 1080kg Torque Rating 535Nm (395ft.lbs) 610Nm (450ft.lbs) Bearing Contact Diameter 44-52mm 44-52mm Bearing Load (@ 48mm) 210kg 260kg Release Travel Required 5mm 5mm Assembly Mass (without flywheel) 3.10kg 3.10kg Disc Set Static Mass 0.6kg Friction Thickness New 6.35mm (0.250") 6.35mm (0.250") Friction Thickness Worn 5.58mm (0.220") 5.58mm (0.220") Product Features: Push type billet alloy cover 4140 Chromoly pressure plate Hardened steel wear posts High and low ratio pressure plate options Low inertia Serviceable components SFI certified design

Applications

- Suzuki/Swift/Gen. III | 1.3 (RS 413)/2005.02-2011/M13A 1328 Petrol 68 kW 92 BHP (2005.02 - 2011) , \n - Suzuki/Ignis/MH | 1.5 (RM415)/2003.09-2005/M15A 1490 Petrol 73 kW 99 BHP (2003.09-2005) , \n - Suzuki/Ignis/MH | 1.5 4x4 (RM415)/2003.09-2005/M15A 1490 Petrol 73 kW 99 BHP (2003.09-2005) , \n - Suzuki/Swift/Gen. III | 1.5 (RS 415)/2005.02-2011/M15A 1490 Petrol 75 kW 102 BHP (2005.02 - 2011) , \n - Suzuki/Ignis/FH | 1.5 Sport (RG415)/2003.12-2005.12/M15A 1490 Petrol 80 kW 109 BHP (2003.12 - 2005.12) , \n - Suzuki/Ignis/FH | 1.5 (HV81. RG415)/2003.08-2005.12/M15A 1490 Petrol 83 kW 113 BHP (2003.08 - 2005.12) ,

Additional Info

Clutch Disc Diameter (mm): 184\nClutch Disc Spline Count: 18\nClutch Disc Spline Diameter (mm): 19.3\nTorque (Nm): 610\nFlywheel Step: +2.5mm\nDesign: Single Plate\nStage: Track Use Only\nTech Bulletins: \nClamp Load: \nRecommended for: \nRing Gear Tooth count: \nAdditional infotmation:

Single Plate

Vehicle group: Suzuki Swift Gen. III

Fitment details:

Make / Model / Variant / Year	Engine	Description	Note	Parameter 1	Parameter 2	Parameter 3
Suzuki Swift Gen. III | 1.3 (RS 413) (2005.02-2011)	M13A 1328 Petrol 68 kW 92 BHP (2005.02 - 2011)			nan	nan	nan
Suzuki Swift Gen. III | 1.5 (RS 415) (2005.02-2011)	M15A 1490 Petrol 75 kW 102 BHP (2005.02 - 2011)			nan	nan	nan

Xtreme products are special order and may be on backorder. If you require this urgently please get in touch before ordering to check stock. You will be contacted within 24 hours of your order if it is on backorder
